High Power Half Cut Mono 445W Solar Energy Panel
Product Advantages
High Power Half Cut Mono 445W Solar Energy Panel
● PID Resistance.
● Higher Power Output.
● 9 Bus Bar Half Cut Cell with PERC Technology.
● Strengthened Machanical Support 5400 Pa Snow Load, 2400 Pa wind Load.
● 0~+5W Positive Tolerance.
● Better Low-light Performance.
Product Parameters
| External Dimensions | 2094x1038x35 mm |
| Weight | 23.5 kg |
| Solar Cells | PERC Mono 166x83mm (144 pcs) |
| Front Glass | 3.2mm AR coating tempered glass, low iron |
| Frame | Anodized aluminum alloy |
| Junction Box | IP68, 3 diodes |
| Output Cables | 4.0 mm2, 250mm(+)/350mm(-) or Customized Length |
| Mechanical Load | Front side 5400Pa / Rear side 2400Pa |
Product Details
Tempered Glass
● Low iron tempered embosses glass.
● 3.2mm thickness, enhance the impact resistance of modules.
● Self-cleaning function.
● The bending strength is 3-5 times that of ordinary glass.
10BB Mono solar cell
● Half cut mono solar cells, to 23.7% efficiency.
● High-precision screen printing to ensure accurate grid position for automatic soldering and laser cutting.
● No color difference, outstanding appearance.
Junction Box
● 2 to 6 terminal blocks can be set as needed.
● All connection methods are connected by quick plug-in.
● The shell is made of imported high-grade raw materials and has high-grade raw materials and has high anti-aging and UV resistance.
● IP67&IP68 rate protection level.
Aluminum Alloy Frame
● Silver frame as optional.
● Strong corrosion and oxidation resistance.
● Strong strength and firmness.
● Easy to transport and install, even if the surface is scratched, it will not oxidize and will not affect performance.
EVA film
● Enhance the light transmission of the components.
● The cells are packaged to prevent the extemal environment from affecting the electrical performance of the cells.
● Bonding solar cells, tempered glass, TPT together, with a certain bond strength.
Technical Specification
Electrical Characteristics
Maximum Power at STC (Pmp): STC445, NOCT330
Open Circuit Voltage (Voc): STC49.9, NOCT46.4
Short Circuit Current (Isc): STC11.34, NOCT9.11
Maximum Power Voltage (Vmp): STC41.6, NOCT38.3
Maximum Power Current (Imp): STC10.7, NOTC8.62
Module Efficiency at STC(ηm): 20.47
Power Tolerance: (0,+4.99)
Maximum System Voltage: 1500V DC
Maximum Series Fuse Rating: 20 A
*STC: lrradiance 1000 W/m² module temperature 25°C AM=1.5
Power measurement tolerance: +/-3%
Temperature Characteristics
Pmax Temperature Coefficient: -0.34 %/°C
Voc Temperature Coefficient: -0.26 %/°C
Isc Temperature Coefficient: +0.05 %/°C
Operating Temperature: -40～+85 °C
Nominal Operating Cell Temperature(NOCT): 45±2 °C
Products Application
Production Process
Project Case
Exhibition
Package&Delivery
Why Choose Autex?
Autex construction group co., ltd. is a global clean energy solution service provider and high-tech photovoltaic modulemanufacturer. We are committed to providing one-stop energy solutions including energy supply, energy management and energy storage to customers around the world.
1. Professional design solution.
2. One-Stop purchasing service provider.
3. Products can be customized according the needs.
4. High quality pre-sales and after-sales service.
